PAINT CHART  3



Factory Code

Colour Name

Year Range

Notes

ACM/214

Brazilia Brown - met

76-80

ex-Rover

ADA/275

Caramel - met

73-82

ADR/259

Sable

68-76

Cellulose

ADS/262

Carriage Brown

76-78

Cellulose

AEA/299

Portland Beige

80-84

AEB/298

Grosvenor Brown

80-86

AER

Light Beige

97-01



AFK/344

Cygnet



was Antelope

AFL/345

Sandpiper Brown - met

87

was Mid Brown, then Bronze

AFM/322

Antelope - met

82-86



AFT/704

Curlew Brown - met

84-86

AFV/711

Woodsmoke - met

86-87

now AGA/747

AFZ/791

Light Brown - met

93

AGA/747

Satin Beige - met

87

was AFV/711

AGB/763

Sandstone - met

93-95

Insignia Range

ANC/320

Cirrus

82-84



ANK/727

Mid Beige - met



ANL/739

Chocolate mica-met



was Mauve mica (pearl?)

ANM/730

Litho Purple - met



ANY/802

Mahogany - met

93-95

Insignia Range

ANZ/764

Saturn Orange mica-met

93-95

Insignia Range

BDA/292

Chestnut Brown - met

78-84

BDB/267

Moroccan Bronze

78-83

Cellulose

BDD/710

Bronze



BDE/1921

Roman Bronze - met

00-01



BEC/174

Black Crystal - met

88-94

BL code (BLVC5)

CCE/211

Richlieu



ex-Rover

CDN/303

Garnet Red - met



CEG

Claret





CEZ/733

Special Pearl Red - met



CFB/737

Dark Red mica-met



now PDP/737

CFD/736

Fireglow



CFE/726

Crimson pearl-met



CGJ/1898

Jupiter Red

0



CHB

Radiance - met

04-Jun



CHA

Salsa

5



CLR7

Opalescent Maroon - met

61-68



CLR23

Opalescent Light Maroon - met

65-71



CDF/258

Signal Red

68-78

Cellulose

CDJ/287

Sebring Red

77-86

was Carnelian

CDG/211

Damson Red

78-79

ex-Rover, was Richlieu

CDM/302

Imperial Crimson

80-84

Cellulose

CEA/310

Claret - met

81-86

CEL/329

Burgundy

83



CEE/316

Cranberry Red - met

83-86

CEJ/343

Amaranth Red - met

86

was Dark Red

CEV/714

Crimson - met

86-88

now CFF/772

CEH/332

Grenadier Red

86-90

was Lancia Red, then Mid Red

CEK/340

Bordeaux Red - met

86-91

was Mid Red, Wine, Rouge

CFC/748

Signal Red

87-96

was Bright Fireglow

CFF/772

Crimson - met

88-89

was CEV/714

CFA/734

Regency Red mica-met

89-94

was Red mica

CFH/765

Flamenco Red mica-met

90-95

was Bright Red

CFJ/736

Meteor Red

93

was Red

CFG/778

Morocco Red mica-met

93-96

CDR/854

Maroon

95-96



CDS/855

Red

95-96



CFS/811

Carnival mica-met

96-98



CFW/819

Cabernet - met

97



CGA/836

Bright Red mica

97



CGE/819

Cabernet pearl-met

97



CGF/881

Madeira mica-met

98



CGH/1881

Madeira pearl-met

98-02



CGG/1811

Carnival pearl-met

98-03



CGL/1924

Phoenix Red

98-04



D1184

New Birch Grey

33



D1267

Cream

33-38

aka Ivory

D1283

Grey

33-38



D1285

Special Maroon

38

D1306

Nile Blue

33-38



D1308

Silver

38

also listed as D3129?

D1319

Olive Green

33-37



D1327

Dark Blue

33-38



D1339

Lavender

33-38

aka Lavender Grey for 1937/8

D1670

Maroon

33-38



D1828

Suede Green

33-38



D1885

Gunmetal

38



D1974

Mountain Ash Green

38



D1980

Amaranth Red

38



D2019

Green Grey

38

D2023

Birch Grey

38



D2024

Battleship Grey

38



D2032

Honeysuckle

33-38



D2048

Green

38



D2049

Red

38



D2149

Special Grey

39

D2599

Olive Green

37-38



DDC/277

Mink - met

77-81

EDA/279

Coral - met

72-77

EDD/837

Burnished Orange mica

97



FCA

Almond

74



FCB/212

Turmeric Yellow

76

ex-Rover

FDA/252

Greensand

72-77

Cellulose

FDB/251

Pale Primrose

63-77

Cellulose, aka Primrose

FDD/266

Yellow Gold

76-78

Cellulose

FDE/212

Cotswold Yellow

78-81

ex-Rover, was Turmeric

FDH/830

Primrose Pearl pearl-met

93-95



GDA/280

Silversand - met

73-86

GDB/306

Coronet Gold - met

81-84

GDD/346

Regal Gold - met



was Coronet Gold

GDE/347

Georgian Gold - met



was Light Gold, then Maya

GDF/341

Sovereign Gold - met

86-88

was Pale Gold, then Beige Opale

GDH/703

Sheraton Gold - met



was Texas Gold

GDJ/707

Filigree Gold - met



GDK

Rolls Royce Gold



GL5030

Black

66-74



HAF/281

Poseidon



ex-Triumph

HDG

Sage - met

70-76

Cellulose

HDH/253

Fern Grey

72-77

Cellulose

HDJ/254

British Racing Green

67-78

Cellulose

HDK/278

Mistletoe - met

78-84

HDM/264

Juniper Green

77-78

Cellulose

HDN/281

(Jaguar) Racing Green - met

78-85

HDS/852

Aegean Green

95-96



HEA/294

April Green - met

81-84



HEB

Dark Green



HEF/304

Evergreen - met

81-84

Factory Code

Colour Name

Year Range

Notes

HEG/314

Sage Green - met

83-86

HEH/318

Dark Green

77



HEJ/339

Serpentine - met

84

was Sage Green

HEK/334

Jaguar Dark Green



HEL/325

Dark Green

83-85



HEM/423

Opaline Green



HEN/701

Jaguar Racing Green

86-89

was Dark Green, then Grand Prix Green

HEP

Gavin Green



Jaguar Special

HER/705

Jaguar Racing Green

85-86

HES/709

Alpine Green - met

86-89

was Catkin

HET/717

Moorland Green - met

86-89

was Leaf Green

HEV/735

Jade Green mica-met

90-97

was Green mica, then Alpine Green

HEW/729

Dark Frond Green - met



HFB/753

Brooklands Green

90-98

was Dark Green

HFC/782

Spearmint - met



HFD/777

Catkin mica-met

92

HFE/779

Kingfisher Blue - met

92-96

was Dark Lagoon

HFG/788

Mid Green - met



HFH/790

Mineral Green - met

93-95

was Dk Green, now Insignia Range

HFL/823

Spruce mica-met

96-98



HFM/831

Peppermint - met

93-95

Insignia Range

HFR/835

Sherwood - met

97-98



HGA

Light Green

97-01



HGD/1753

British Racing Green

98-06



HGE/1835

Sherwood - met

98



HGF/1880

Alpine Green - met

99-00



HGG/1895

Emerald Green - met

99-02



HGL/1823

Spruce - met

98



HGN/1932

Adriatic Blue pearl-met

01-Mar



HGP/1945

Aspen pearl-met

2



HGZ/1957

Jaguar Racing Green - met

03-Jun



JBC/851

Grey

95-01



JCF/236

Atlantis Blue



ex-Rover colour

JDF

Aegean Blue - met

72-77



JDG/255

Dark Blue

64-77

Cellulose

JDH/256

Lavender Blue

72-77

JDJ/265

Squadron Blue

76-78

Cellulose

JDK

Biascan Blue - met



Cellulose

JDM/286

Cobalt Blue - met

78-86

JDN

Azure Blue

65-75

Special order

JDR

Blue

94



JDS/853

Blue

95-96



JEA/291

Quartz Blue - met

78-80

JEB/301

Indigo Blue

80-81

JEC/307

Sapphire Blue - met

82-85

now JEY/719

JED/309

Kingfisher - met

81-84

JEE/273

Biascan Blue - met

76-81

JEJ/311

Mineral Blue - met

81-84

JEK

Mid Blue

97-01



JEL

Light Blue

97-01



JER/326

Clarendon Blue

84

was Dark Blue

JEV/706

Windsor Blue

85-86

JEW/715

Solent Blue - met



now JFJ/715

JEX/718

Tungsten - met

86-91

JEY/719

Sapphire - met



was JEC/307

JFA

Vauxhall Light Blue





JFC/338

Clipper Blue - met

86

was Abyssal Bue

JFD/331

Ensign Blue



was Mid Blue, then Trafalgar Blue

JFE/337

Arctic Blue - met

86-91

was Light Blue, then Haze Blue

JFG/712

Westminster Blue

86-98

JFJ/715

Solent Blue - met

86-94

was JEW/715

JFM/738

Mid Blue - met



was Dark Blue

JFN/743

Diamond Blue mica-met

89-94

was Light Blue mica, then Silver Blue

JFP/724

Dark Blue - met



JFR/728

Dutch Blue - met



JFS/771

Dark Blue - met



was Dark Slate

JFT/741

Light Blue - met



was Slate

JFW/L113537

Royal Blue



JFX/752

Dark Blue



JFY/786

Blue Pearl mica-met



JFZ/789

Crystal Blue - met

91-93

was Light Blue

JGA/792

Light Blue mica-met



JGB/803

Dark Blue mica-met

93

now JGC/804?

JGC/804

Dark Blue mica-met



was JGB/803?

JGD/805

Dark Blue - met



JGE/806

Sapphire Blue - met

94-98

JGH/799

Crystal Blue - met

93-95

Insignia Range

JGJ/800

Blue Grey - met

96



JGL/822

Dark Blue

96



JGM/818

Dark Blue - met

9



JGP/829

Amethyst - met

93-95

Insignia Range

JGR/833

Lavender - met

93-95

Insignia Range

JGY/839

Aquamarine - met

97-98



JGZ/840

Antigua mica-met

97-98



JHA/861

Mistral - met

98



JHE/1806

Sapphire - met

98-02



JHF/1839

Aquamarine mica-met

98



JHG/1712

Westminster Blue

98-02



JHH/1840

Antigua pearl-met

98-99



JHJ/1861

Mistral - met

98-01



JHM/1905

Pacific Blue pearl-met

00-06



JHV/1927

Zircon pearl-met

02-Jun



JJF/1974

Ultraviolet - met

04-Jun



JS1

Spa - met

92-93

Silver - unique to XJ220

JS2

Le Mans - met

92-93

Dark Blue - unique to XJ220

JS3

Silverstone - met

92-93

Dark Green - unique to XJ220

JS4

Monza - met

92-93

Dark Red - unique to XJ220

JS5

Daytona- met

92-93

Almost Black - unique to XJ220

KDA

Heather

72-75

Cellulose

KDB/274

Amethyst - met

76-79



KDC/780

Medium Slate -





KDD/793

SF Purple - met

96



KDJ/862

Amaranth - met

98



KDK/1862

Amaranth mica-met

98-99



LDC/324

Carlton Grey

73-77

LDD

Light Grey





LDL/315

Regent Grey - met

83-86

LDN/335

Purbeck Grey

84-86

was Cirrus Grey

LDP/342

Dorchester Grey - met

86-89

was Regent Grey

LEB/702

Dove Grey

86-89

was Mid Grey

LEC/708

Steel (Blue) - met

86

LED/713

Savoy Grey - met

86-89

LEH/740

Gunmetal mica-met

90-94

was Grey mica, then Dorchester Grey mica

LEJ/749

Carlton Grey



LEK/731

Savoy Grey - met

89-91

was Taupe

LEL/725

Grey Green - met



now LER/774?

LEN/RR708

Tudor Grey



BASF Rolls Royce colour

Factory Code

Colour Name

Year Range

Notes

LEP/775

Platinum - met

93-94

was New Tungsten

LER/774

Grey Green - met

92

was LEL/725?

LEV/783

Steel Grey pearl-met

95

was Mid Grey

LEW/784

Light Grey - met



LEX/785

Greenish Grey mica-met

93

LFA/810

Titanium mica-met

95-98



LFB/825

Turquoise Grey - met

96



LGA

Grey

95-01



LGB/873

Steel Grey 2 - met

96



LGF/897

Steel Grey 3 - met

97



LGL/1810

Titanium mica-met

98-01



LHK/1926

Quartz - met

02-Jun



LHL/1943

Slate pearl-met

01-Jun



MDB/260

Silver Grey - met

79

Cellulose

MDC

Silver Grey - met





MDD/216

Platinum - met

76-81

ex-Rover, was Silver Frost

MDE/396

Rhodium Silver - met

80-86

MDF/336

Talisman Silver - met

86-90

was Silver

MDG/349

Mother of Pearl - met



was Lilac Silver, then Quartz

MDJ/716

Silver Birch - met

86-88

was Birch Bark

MDK/750

Silver Frost - met

90-95

was Silver

MDM/E8702

Rhodium Silver - met



MDP/821

Ice Blue - met

95-97



MDS/860

Seafrost - met

98



MDT/911

Meteorite - met

98



MDV/1860

Seafrost - met

98-06



MDX/1911

Meteorite - met

98-99



MDY

Silver - met

98



MDZ/1916

Platinum - met

00-06



NCF/215

Tudor White



ex-Rover, was Pendelican

NDB/250

Old English White

70-78

Cellulose

NDC/215

Tudor White

78-86

NDE/319

Ivory



NDF

Special White





NDG/317

Cumulus White

83

NDH/330

Spindrift White



was Cumulus White

NDJ/700

Nimbus White

86-87

was White

NDK/721

Glacier White

87-88

was Police White

NDM/732

Spindrift White

96-98

aka White

NDP/742

Glacier White 2

88-95

NDT/832

White Pearl pearl-met

93-95

Insignia Range (Grundton/Ground)

NDY/841

Warm White

97



NEA/850

Cream

95-96



NEE/1732

Spindrift

98-00



NEG/1942

Onyx

00-06



PDC/90

Black



Cellulose, ex-Austin Morris

PDE/373

Jet Black

80

PDF/308

Sable - met

81-84

PDH/333

Jet Black

86-93

was Black

PDP/737

Black Cherry mica-met

90-93

was CFB/737

PDR/773

Black 120 mica-met



PDT/807

Black

94-98



PDV/824

Nautilus mica-met

96-97



PDX/859

Anthracite pearl-met

97-98



PEB

Black Cherry

97-01



PEC/1807

Black

98

(also listed as 03-06)

PED/1859

Anthracite pearl-met

98-02



PEF

Midnight - met

03-Jun



PMA/90

Maraschino Black

81

Cellulose, aka Black

RDA/DUAL

Silver/Maroon



RDB/DUAL

Carlton Grey/Light Grey





RDC/DUAL

Sebring/Black





RDD/DUAL

Black/Burgundy





RDE/DUAL

Black/Carlton Grey





RDF/DUAL

Black/Rolls Royce Claret





RDG/DUAL

Black/Maroon





RDH/DUAL

Rhodium/Cranberry





RDJ/DUAL

Sapphire/Cobalt



RDK/DUAL

Bronze/Antelope



RDL/DUAL

Sage/Racing Green





RDM/DUAL

Rhodium/Black





RDN/DUAL

Dark Blue/Regent Grey





RDP/DUAL

Rhodium/Burgundy





RDR/DUAL

Regent Grey/Anthracite





RDS/DUAL

Silversand/Burgundy



RDT/DUAL

Black/Citroen Green





RDU/DUAL

Regent Grey/Rhodium



RDV/DUAL

Steel/Cobalt



RDW/DUAL

Rhodium/Windsor



RDX/DUAL

Dark Blue/Carlton Grey





RDY/DUAL

Antelope/Curlew





RDZ/DUAL

Silversand/Black



REA/DUAL

Rhodium/Steel



REC/DUAL

Arctic/Solent





RED/DUAL

Talisman/Solent



REE/DUAL

Talisman/Dorchester



REJ/DUAL

Westminster/Black



REK/DUAL

Silver Birch/Satin Beige



REL/DUAL

Tungsten/Dorchester



REM/DUAL

Tungsten/Solent



REN/DUAL

Westminster/Arctic



REP/DUAL

Arctic/Westminster





RES/DUAL

Tungsten/Gunmetal



RET/DUAL

Satin Beige/Regency



REV/DUAL

Diamond/Solent



REW/DUAL

Black/Regency





REX/DUAL

Solent/Arctic



REY/DUAL

Talisman/Black



REZ/DUAL

Dorchester/Gunmetal



RFH/DUAL ?

Black/Westminster



SDD/754

Tuscany Bronze mica-met

90-93

was Dark Beige

SDE/751

Oyster - met

90-94

 was Light Beige

SDH/787

Reddish Beige mica-met

93

SDL/795

Rose Bronze - met

94-95



SDN/820

Topaz - met

95-98



SDT/838

White Gold - met

97



SEC/1820

Topaz - met

98-06



TDA

Morello



Cellulose

TDB

Aubergine - met

73-77

Cellulose

TDC

Maroon



Cellulose

TDD/257

Regency Red

68-77

Cellulose

TDE

Aubergine - met

72-75

TDF

Aubergine



UDA

Turquoise





UDB/827

Turquoise - met

95-96

aka Bright Turquoise - met

VDA

Turquoise

72-74





Ascot Fawn

68-72
